8MT Professional in medical endoscope microscope;Comply with UHDTV standard 3840*2160@ frames rate up to 4K60 frames, real-time no jitter;The resolution of 4K can provide more than 8 million pixels, achieving film-level picture quality, which is equivalent to more than four times the current full HD 1080p resolution.
| Model | Specification | Image | Size |
|---|---|---|---|
| 8MT |
● For Endoscopy
●3840x2160P 4K60FPS, 8.0MP
● Compatible with 1920*1080P60FPS
● 1/1.8 or 1/1.2” Sony COMS
● USB video recording, capture and playback
● APP network remote on-demand
● Image & touch menu all-in-one LCD front screen ● USB remote upgrade ● Customize boot LOGO |
 |
Camera: φ28mm Motherboard: 120*168mm |
| 8MF |
● For Microscope
●3840x2160P 4K60FPS, 8.0MP
●Compatible with 1920*1080P60FPS
●1/1.8 or 1/1.2” Sony COMS
●USB video recording, capture and playback
●Mouse operation Case editing
●APP network remote on-demand
●Compact size design
●USB remote upgrade
●Wired and wireless control ●Customize boot LOGO |
 |
Camera: φ28mm Motherboard: 69*93mm |
| 2MF |
● For Endoscopy ● 1920*1080P60 frames 2 million pixels ● 1/1.8” or 1/2.8" Sony COMS ● USB recording, taking photos, playback ● USB remote upgrade ● Image & Touch all-in-one LCD front screen ●Customize boot LOGO |
 |
Camera: φ29mm Motherboard: 120*168mm |
Support the rec.2020 color gamut standard, the camera collects the rawdata raw data of the sensor, enters the DSP processing, through the 12bit HDMI2.0 output R, G, B, Y four kinds of adjustable color phase matrix, obtains the richer color reducibility, the color difference Δ C00＜3
The camera handle shell support waterproof up to IP68, support autocalvable; The four shortcut keys on the handle can customize the function.
Watch playback videos and pictures on the host, or copy data to a USB drive. Supports 4K or 1080p resolution video storage and 8 million pixel photography
Provide mobile APP and PC computer-side software, network-on-demand to take real-time images, photos, recording, video editing, etc. One click on the cloud to share clinical pictures and videos.
Built-in HDMI to display both HD image and touch menu. As the front screen or integrated screen of the mainframe
>Touch the UI interface
>Boot LOGO screen
>PCB hardware design
| Model | NP-2MF | NP-8MT | NP-8MF | |
|---|---|---|---|---|
| Resolution | 1920*1080P60Frame | 3840*2160P60Frame | ||
| Sensor | 1/2.8”1/1.8” COMS | 1/1.8”1/1.2” COMS | ||
| Resolution | ≥800 Line | ≥1600 Line | ||
| color | 3500k、6500k,7500k,Custom definition | |||
| Custom button | White balance, freezing, video recording, photography, scene switching, magnification, color, brightness, elimination of moire lines | |||
| Application department | Stomatology, plastic surgery, otorhinolaryngology, general surgery, neurosurgery, ophthalmology | |||
| storage device | USB disk or removable hard disk | USB disk or removable hard disk or SD card | ||
| Playback | Videos and pictures | |||
| Video | 1920*1080P | 3840*2160P | ||
| Video file | 30 minutes / MP4 format | 30mur120 minutes / MP4 format | ||
| Coding technology | H264/H265 | |||
| Take a picture | 200Ten thousand/JPGFormat | 800万/JPGFormat | ||
| Output interface | 2xHDMI+1xDVI+1xSDI+1xCVBS+2xUSB+Net port | HDMI（2.0）+HDMI（1.4）+DVI+SDI+3xUSB3.0+Network | HDMI（2.0）+2xUSB3.0+SD卡 + Audio + Wired / Wireless remote Control + Network | |
| SDK protocol | Provide Rs232 protocol | Provide Rs232 protocol, network transport protocol, etc. | ||
| Audio frequency | Not supported | Support | ||
| Remote control | Support | |||
| Mouse keyboard | Support | |||
| Foot switch | Support | |||
| Camera size | Diameter 28mm double layer plate | |||
| Motherboard size | 69*93mm | |||
| Language | Chinese, English, Russian, Spanish, (Portuguese, German, French available) | |||
| The advantages of our products | Security, industrial cameras | |
|---|---|---|
| structure |
1. Miniaturized camera (such as coin size):
The handle shell of the camera can be designed to be very lightweight and ergonomic. 2. Camera module ISP split design, low power consumption, no heating, more stable, low failure rate. 3, copper axis cable connection, simple and strong shielding, not easy to be disturbed, lower after-sales maintenance cost. no, no, no. |
1. At present, most of the low-end low-end endoscope cameras on the market use security surveillance cameras, that is, the sensors and processors are on the same circuit board, resulting in high heat generation and high defect rate after working for a long time. 2. The low-end camera is basically made up of the camera and the back-end signal adapter board, and the signal is easy to attenuate and unstable. 3, can not pass the medical EMC and safety regulations and other certification, the rectification process is very complicated. |
| Software |
1. The large target surface of the camera sensor (1ax 1.8 ") is more suitable for the application of endoscope: in low light, the color and clarity are still excellent. 2. Specially aim at the color temperature of the light source of the medical microscope, correct the color under the professional color temperature light box, ensure the color reducibility and ensure that the color is not biased after bleeding. 3. With the inherent advantage of Sony backlight sensor, ultra-high sensitivity is more suitable for ophthalmic microscope; ultra-high width dynamic: near teeth block, distant tissue can still be seen. 4. the self-developed photometric intelligent algorithm can suppress the reflection of the instrument and improve the comfort of the doctor's operation. |
According to the software debugged in the industrial security environment, most industrial security cameras have mediocre clarity and color reduction under the low illumination of the endoscope; The industrial security camera has not debugged the software specifically for the medical surgery scene: inaccurate white balance, color deviation after bleeding, poor permeability and dynamic range; did not do any processing when confronted with metal equipment reflection. |
| Application |
1. At most 4 interfaces output video to the monitor to facilitate the attending doctor / assistant to watch the screen from different angles at the same time. 2. Support high-definition image and touch interface on the same screen, integrated design, simple, convenient and fast. 3. Support wired and wireless remote control pedal switches, support USB mouse and keyboard devices, edit case information directly, and even print reports 4. Support network on-demand and sharing, watch videos on mobile phone, and support medical standard DICOM protocol. 5. Support remote USB disk upgrade without going to the customer site for maintenance. |
1.Most of the video signal transfer boards do not support the recording function, which requires an external video recording module, which increases the extra cost and instability, and the picture quality is lost; 2. Lack of many applications specifically for medical endoscopes with low extensibility, and can not modify or expand any other applications. |
